LG Display LP133WX2-TLC3 Dateblat, Spezifizéierung, Aktien, Applikatioun www.looklcd-lu.com
LookLCD LookLCD


LP133WX2-TLC3

LP133WX2-TLC3
LP133WX2-TLC3
LP133WX2-TLC3 thumb LP133WX2-TLC3 thumb
Mark
LG Display
Gréisst
13.3
Applikatioun
NBPC
Opléisung
1280×800
Zesummesetzung
LCM
Hellegkeet
275
CR
600:1
Faarwen
262K
Backlight
WLED
Interface
LVDS
In Stock
16627
Spezifikatioune

Part Number LP133WX2-TLC3
MarkLG Display
Gréisst13.3
ApplikatiounNBPC
Opléisung1280×800
ZesummesetzungLCM
Hellegkeet275
CR600:1
Faarwen262K
GéigeliichtWLED
InterfaceLVDS
Panel MarkLG.Philips LCD
Panel ModellLP133WX2-TLC3
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst13.3 inch
Resolutioun1280(RGB)×800 , WXGA
Display ModusTN, Normally White, Transmissive
aktiv Beräich286.08×178.8 mm
skizzéieren297.15×192.15×3.6 mm
Form StilFlat (PCBA Flat, Depth 3.4~4.0mm)
UewerflächGlare (Haze 0%), Hard coating (2H), Antireflection
Hellegkeet275 cd/m² (Typ.)
Kontrast Verhältnis600:1 (Typ.)
weisen Faarwen262K (6-bit)
Äntwert Zäit16 (Typ.)(Tr+Td)
Vue Wénkel45/45/15/35 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe Typ5 stringsWLEDWithout Driver
Signal InterfaceLVDS (1 ch, 6-bit), 30 pins
Input Volt3.3V (Typ.)
ApplikatiounNBPC
