LG Display LP125WH2-TLFA Dateblat, Spezifizéierung, Aktien, Applikatioun www.looklcd-lu.com
LookLCD LookLCD


LP125WH2-TLFA

LP125WH2-TLFA
LP125WH2-TLFA
LP125WH2-TLFA thumb LP125WH2-TLFA thumb
Mark
LG Display
Gréisst
12.5
Applikatioun
NBPC
Opléisung
1366×768
Zesummesetzung
LCM
Hellegkeet
200
CR
300:1
Faarwen
262K
Backlight
WLED
Interface
LVDS
In Stock
13598
Spezifikatioune

Part Number LP125WH2-TLFA
MarkLG Display
Gréisst12.5
ApplikatiounNBPC
Opléisung1366×768
ZesummesetzungLCM
Hellegkeet200
CR300:1
Faarwen262K
GéigeliichtWLED
InterfaceLVDS
Panel MarkLG Display
Panel ModellLP125WH2-TLFA
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst12.5 inch
Resolutioun1366(RGB)×768 , WXGA
Display ModusTN, Normally White, Transmissive
aktiv Beräich276.615×155.52 mm
skizzéieren290.5×179.5×3.8 mm
Form StilFlat (PCBA Flat, Depth 3.4~4.0mm)
UewerflächAntiglare
Hellegkeet200 cd/m² (Typ.)
Kontrast Verhältnis300:1 (Min.)
weisen Faarwen262K (6-bit), CIE193146%
Äntwert Zäit16 (Typ.)(Tr+Td)
Vue Wénkel40/40/10/30 (Min.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe TypWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (1 ch, 6-bit), 40 pins
Input Volt360/415mA (Typ./Max.)
ApplikatiounNBPC
Famill Modell
LP125WF1-SPA2 LG Display 12.5 1920×1080
LP125WF2-SPB1 LG Display 12.5 1920×1080
LP125WF2-SPB3 LG Display 12.5 1920×1080
LP125WH2-SLB2 LG Display 12.5 1366×768
LP125WH2-SLB3 LG Display 12.5 1366×768
LP125WH2-SPR1 LG Display 12.5 1366×768
LP125WH2-SPT1 LG Display 12.5 1366×768
LP125WH2-TLB1 LG Display 12.5 1366×768
LP125WH2-TLD1 LG Display 12.5 1366×768
LP125WH2-TLE1 LG Display 12.5 1366×768
