| Part Number | LM116LF3L02 |
| Mark | PANDA |
| Gréisst | 11.6 |
| Applikatioun | Pad & Tablet |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM , Oxide TFT-LC |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED , 15K hours , With LED Driver |
| Interface | eDP |
| Fabrikant beschwéiert | PANDA |
| Modell Numm | LM116LF3L02 (NCP0000) |
| Écran Gréisst | 11.6 inch |
| Écran Typ | LCM , Oxide TFT-LCD |
| Pixel Zuel | 1920(RGB)×1080 (FHD) 190PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 256.32 × 144.18 (H×V) |
| Kontur (mm) | 268 × 168 × 3 (H×V×D) |
| Bezel Beräich (mm) | - |
| Behandlung | Antiglare, Hard coating (3H) |
| luminance | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000 : 1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Äntwert | 25 (Typ.)(Tr+Td) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | FFS, Normally Black, Transmissive |
| Faarfdéift | 16.7M 100% sRGB |
| mass | 215g (Max.) |
| benotzt fir | Pad & Tablet |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Signal Typ | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| Spannungsversuergung | 3.3V (Typ.) |
| max. Bewäertungen | Storage Temp.: -20 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
