| Part Number | LM116LF3L01 |
| Mark | PANDA |
| Gréisst | 11.6 |
| Applikatioun | Pad & Tablet |
| Opléisung | 1920×1080 |
| Zesummesetzung | Oxide TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | eDP |
| Mark | PANDA |
| diagonal Gréisst | 11.6 inch |
| Pixel Format | 1920(RGB)×1080 [FHD] 190PPI |
| aktiv Beräich | 256.32(H)×144.18(V) mm |
| bezel Beräich | - |
| luminance | 300 cd/m² (Typ.) |
| Vue Richtung | Symmetry |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Ënnerstëtzung Faarf | 16.7M 100% sRGB |
| Gewiicht | 215g (Max.) |
| Frame Taux | 60Hz |
| Interface Typ | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -10 ~ 60 °C ; Storage Temperature: -20 ~ 70 °C |
| Modell | LM116LF3L01 (NCP000A) |
| Typ | Oxide TFT-LCD , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 268(H)×168(V) ×3(D) mm |
| Behandlung | Antiglare, Hard coating (3H) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Betribssystemer Modus | FFS, Normally Black, Transmissive |
| Liichtquell | WLED , 15K hours , With LED Driver |
| entworf fir | Pad & Tablet |
| Touch Panel | Without |
