| Part Number | LK695D3LA18 |
| Mark | SHARP |
| Gréisst | 70 |
| Applikatioun | PID |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM |
| Hellegkeet | 350 |
| CR | 4000:1 |
| Faarwen | 1.07B |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | SHARP |
| Panel Modell | LK695D3LA18 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 70 inch |
| Resolutioun | 1920(RGB)×1080 , FHD |
| Display Modus | ASV, Normally Black, Transmissive |
| aktiv Beräich | 1538.88×865.62 mm |
| skizzéieren | 1566×901.8 mm |
| Uewerfläch | Antiglare, Hard coating (2H) |
| Hellegkeet | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 4000:1 (Typ.) |
| weisen Faarwen | 1.07B (10-bit) |
| Äntwert Zäit | 4/6 (Typ.)(Tr/Td) |
| Vue Wénkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 120Hz |
| Lampe Typ | 3 stringsWLEDWithout Driver |
| Signal Interface | LVDS (4 ch, 10-bit), 92 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | PID |
