| Part Number | LH400WV3-SD02 |
| Mark | LG Display |
| Gréisst | 4.0 |
| Applikatioun | MPH |
| Opléisung | 480×800 |
| Zesummesetzung | LCM |
| Hellegkeet | 700 |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | MIPI |
| Panel Mark | LG Display |
| Panel Modell | LH400WV3-SD02 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 4.0 inch |
| Resolutioun | 480(RGB)×800 , WVGA |
| Display Modus | IPS, Normally Black, Transmissive |
| aktiv Beräich | 51.84×86.4 mm |
| skizzéieren | 55.54×95.8 mm |
| Uewerfläch | |
| Hellegkeet | 700 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193170% |
| Äntwert Zäit | 40 (Typ.)(Tr+Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Lampe Typ | 1S8PWLEDWithout Driver |
| Signal Interface | MIPI (2 data lanes), 30 pins |
| Input Volt | 1.8/3.1V (Typ.)(VCC/IOVCC) |
| Applikatioun | MPH |
| ACX435AKN-7 | SONY | 4.5 | 800×1280 |
| AMS369FG06-0 | Samsung | 3.7 | 480×800 |
| CM520F1-001 | CSOT | 5.2 | 1080×1920 |
| DLC0240LZG-4 | Other | 2.4 | 240×320 |
| H466TAN01.1 | AUO | 4.7 | 720×1280 |
| LH450WX3-SD01 | LG Display | 4.5 | 720×1280 |
| LQ055T3SX02 | SHARP | 5.5 | 1080×1920 |
| LS047T1SC01K | SHARP | 4.7 | 1080×1920 |
| OEL9M0039-G-E | Other | 1.5 | 128×128 |
| TM028HBHG02 | Tianma | 2.8 | 240×320 |
