| Part Number | LD860DBN-UJA2 |
| Mark | LG Display |
| Gréisst | 86 |
| Applikatioun | Digital Signage Outd |
| Opléisung | 3840×600 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1100:1 |
| Faarwen | 1.07B |
| Géigeliicht | WLED |
| Interface | V-by-One |
| Mark | LG Display |
| Modell | LD860DBN-UJA2 |
| diagonal Gréisst | 86 inch (Native bar) |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 3840(RGB)×600 45PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 2148.48(H)×335.7(V) mm |
| kontur dim. | 2158.3(H)×348.5(V) ×82.2(D) mm |
| bezel Beräich | 2149.5(H)×336.7(V) mm |
| Behandlung | Antiglare (Haze 10%), Hard coating (3H) |
| luminance | 700 cd/m² (Typ.) |
| Kontrast Verhältnis | 1100:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 8 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Min.)(CR≥10) |
| Betribssystemer Modus | IPS, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 1.07B 98% sRGB |
| Liichtquell | WLED , 50K hours , With LED Driver |
| Gewiicht | 15.04Kgs (Typ.) |
| entworf fir | Digital Signage Outdoor High Brightness Stretched Bar LCD |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | V-by-One 8 lane , 51 pins Connector |
| Stroumversuergung | 12.0V (Typ.) |
| Ëmwelt | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
