| Part Number | LD470DXS-SCB1 |
| Mark | LG Display |
| Gréisst | 47 |
| Applikatioun | DID |
| Opléisung | 1366×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 500 |
| CR | 1400:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | LG Display |
| Panel Modell | LD470DXS-SCB1 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 47 inch |
| Resolutioun | 1366(RGB)×768 , WXGA |
| Display Modus | S-IPS, Normally Black, Transmissive |
| aktiv Beräich | 1039.87×584.64 mm |
| skizzéieren | 1046.8×591.6×50.5 mm, Videowall Seam 6.9 mm |
| Uewerfläch | Antiglare (Haze 10%), Hard coating (3H) |
| Hellegkeet | 500 cd/m² (Typ.) |
| Kontrast Verhältnis | 1400:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193172% |
| Äntwert Zäit | 12 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 8-bit), 30 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | DID |
