| Part Number | LD320EUY-SQA3 |
| Mark | LG Display |
| Gréisst | 32.0 |
| Applikatioun | Digital Signage |
| Opléisung | 1920×1080 |
| Zesummesetzung | a-Si TFT-LCD, CELL |
| Hellegkeet | |
| CR | 1300:1 |
| Faarwen | 1.07B |
| Géigeliicht | No |
| Interface | LVDS |
| Panel Mark | LG Display |
| Panel Modell | LD320EUY-SQA3 |
| Panel Gréisst | 32.0" |
| Panel Typ | a-Si TFT-LCD, CELL |
| Resolutioun | 1920(RGB)×1080, FHD, 69PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 698.4(W)×392.85(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 708.4(W)×405.4(H) ×1.2(D) mm |
| Uewerfläch | Antiglare (Haze 3%), Hard coating (2H) |
| Hellegkeet | 0 cd/m² |
| Kontrast Verhältnis | 1300:1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Min.)(CR≥10) |
| Display Modus | IPS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 6 (Typ.)(G to G) |
| Glas Déift | 0.40+0.50 mm |
| transmissivitéit | 5.75% (Typ.)(with Polarizer) |
| weisen Faarwen | 1.07B |
| Lampe Typ | No B/L |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Chauffeur ic | COFBuilt-in 6 source chips |
| Panel Gewiicht | 0.78/0.80Kgs (Typ.) |
| Applikatioun | Digital Signage |
| Signal Interface | LVDS (2 ch, 8-bit) , 51 pins Connector |
| Input Volt | 12V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| BRS-320H02 | 32.0 | 1920×1080 | |
| LD320EUN-SEM1 | LG Display | 31.5 | 1920×1080 |
| M320QAN01.0 | AUO | 32.0 | 3840×2160 |
| V320B1-L01 | Innolux | 32.0 | 1366×768 |
| V320B1-L06 | Innolux | 32.0 | 1366×768 |
