| Part Number | LD290EJN-FPN1 |
| Mark | LG Display |
| Gréisst | 28.6 |
| Applikatioun | Digital Signage Stre |
| Opléisung | 1920×540 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | 4 strings WLED , 50K hours , No Driver |
| Interface | LVDS |
| Fabrikant beschwéiert | LG Display |
| Écran Gréisst | 28.6 inch (Native bar) |
| Pixel Zuel | 1920(RGB)×540 69PPI |
| aktiv Beräich (mm) | 698.4 × 196.425 (H×V) |
| Bezel Beräich (mm) | 700.4 × 198.44 (H×V) |
| luminance | 500 cd/m² (Typ.) |
| Vue Wénkel | 89/89/89/89 (Min.)(CR≥10) |
| gutt Vue op | Symmetry |
| Faarfdéift | 16.7M 72% NTSC |
| mass | 1.80/2.00Kgs (Typ./Max.) |
| Erfrëschungsrate | 60Hz |
| Signal Typ | LVDS (2 ch, 8-bit) , 51 pins Connector |
| Spannungsversuergung | 12.0V (Typ.) |
| max. Bewäertungen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Modell Numm | LD290EJN-FPN1 |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 712.8 × 213.74 (H×V×D) |
| Behandlung | Antiglare, Hard coating (4H) |
| Kontrast Verhältnis | 1000 : 1 (Typ.) (TM) |
| Äntwert | 6 (Typ.)(G to G) ms |
| Aarbecht Modus | IPS, Normally Black, Transmissive |
| benotzt fir | Digital Signage Stretched Bar LCD |
| touchscreen | In-Cell Touch |
