| Part Number | LD070WS2-SL02 |
| Mark | LG Display |
| Gréisst | 7.0 |
| Applikatioun | UMPC |
| Opléisung | 1024×600 |
| Zesummesetzung | LCM |
| Hellegkeet | 400 |
| CR | 800:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | LG Display |
| Panel Modell | LD070WS2-SL02 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 7.0 inch |
| Resolutioun | 1024(RGB)×600 , WSVGA |
| Display Modus | IPS, Normally Black, Transmissive |
| aktiv Beräich | 153.6×90 mm |
| skizzéieren | 162.8×102.9×2.67 mm |
| Uewerfläch | Hard coating |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) |
| weisen Faarwen | 262K/16.7M (6-bit / 6-bit + Hi-FRC) |
| Äntwert Zäit | 50 (Max.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 5S4PWLEDWithout Driver |
| Signal Interface | LVDS (1 ch, 8-bit) + SPI, 30 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | UMPC |
| LD070WS1-SL02 | LG Display | 7.0 | 1024×600 |
| LD070WS2-SL02 | LG Display | 7.0 | 1024×600 |
| LD070WS2-SL04 | LG Display | 7.0 | 1024×600 |
| LD070WS2-SL06 | LG Display | 7.0 | 1024×600 |
| LD070WS2-SL07 | LG Display | 7.0 | 1024×600 |
| LD070WU2-SH01 | LG Display | 7.0 | 1200×1920 |
| LD070WU2-SM01 | LG Display | 7.0 | 1200×1920 |
| LD070WX4-SM01 | LG Display | 7.0 | 800×1280 |
| LD070WX5-SM01 | LG Display | 7.0 | 900×1440 |
| LD070WX6-SM01 | LG Display | 7.0 | 800×1280 |
| BP070WX1-100 | BOE | 7.0 | 1280×800 |
| HV056WX1-100 | HYDIS | 5.6 | 1280×800 |
| HV070WSA-100 | BOE | 7.0 | 1024×600 |
| LD070WS1-SL02 | LG Display | 7.0 | 1024×600 |
| LD070WS2-SL05 | LG Display | 7.0 | 1024×600 |
| LD070WS2-SL07 | LG Display | 7.0 | 1024×600 |
| LT080EE04000 | TOSHIBA | 8.0 | 1600×768 |
| LTD056ET2F | TOSHIBA | 5.6 | 1024×600 |
| LTL070AL01-L01 | Samsung | 7.0 | 1280×800 |
| N070ICG-LD1 | Innolux | 7.0 | 1280×800 |
