| Part Number | LC550DQJ-SMA1 |
| Mark | LG Display |
| Gréisst | 55 |
| Applikatioun | TV Sets |
| Opléisung | 3840×2160 |
| Zesummesetzung | a-Si TFT-LCD , CELL |
| Hellegkeet | |
| CR | 1300:1 |
| Faarwen | 1.07B |
| Géigeliicht | No |
| Interface | EPI |
| Mark | LG Display |
| diagonal Gréisst | 55 inch |
| Pixel Format | 3840(RGB)×2160 [UHD] 80PPI |
| aktiv Beräich | 1209.6(H)×680.4(V) mm |
| bezel Beräich | - |
| luminance | 0 cd/m² |
| Vue Richtung | Symmetry |
| Vue Wénkel | 89/89/89/89 (Min.)(CR≥10) |
| Plackedicke | - |
| Ënnerstëtzung Faarf | 1.07B |
| Gewiicht | 2.50/2.63Kgs (Typ./Max.) |
| Frame Taux | 60Hz |
| d-ic detail | COF Built-in 6 source chips |
| Interface Typ | EPI , 120 pins Connector |
| Stroumversuergung | 12.0V (Typ.) |
| Ëmwelt | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Modell | LC550DQJ-SMA1 |
| Typ | a-Si TFT-LCD , CELL |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 1221.4(H)×694.8(V) ×1.2(D) mm |
| Behandlung | Antiglare (Haze 3%), Hard coating (2H) |
| Kontrast Verhältnis | 1300:1 (Typ.) (TM) |
| Äntwert Zäit | 8/10 (Typ.)(Tr/Td) |
| Betribssystemer Modus | IPS, Normally Black, Transmissive |
| Iwwerdroung | 5.49% (Typ.)(with Polarizer) |
| Liichtquell | No B/L |
| entworf fir | TV Sets |
| Touch Panel | Without |
| LC550DUE-FGP2 | LG Display | 55 | 1920×1080 |
| LC550DUE-MGA3 | LG Display | 55 | 1920×1080 |
| LC550DUF-VGF1 | LG Display | 55 | 1920×1080 |
| LC550DUH-PGF2 | LG Display | 55 | 1920×1080 |
| LC550DUJ-SGE1 | LG Display | 55 | 1920×1080 |
| LC550DUN-PGP1 | LG Display | 55 | 1920×1080 |
| LC550DUN-PGP2 | LG Display | 55 | 1920×1080 |
| LC550DUN-SFU2 | LG Display | 55 | 1920×1080 |
| LC550DUS-SCM3 | LG Display | 55 | 1920×1080 |
| LC550DUY-SHA1 | LG Display | 55 | 1920×1080 |
