| Part Number | LC550DGJ-SLA1 |
| Mark | LG Display |
| Gréisst | 55 |
| Applikatioun | TV Sets |
| Opléisung | 38403×2160 |
| Zesummesetzung | a-Si TFT-LCD, CELL |
| Hellegkeet | |
| CR | 1300:1 |
| Faarwen | 16.7M |
| Géigeliicht | No |
| Interface | EPI |
| Panel Mark | LG Display |
| Panel Modell | LC550DGJ-SLA1 |
| Panel Gréisst | 55" |
| Panel Typ | a-Si TFT-LCD, CELL |
| Resolutioun | 3840(3)×2160, UHD, 80PPI |
| Pixel Format | RGBW Vertical Stripe |
| Affichage Beräich | 1209.6(W)×680.4(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 1221.4(W)×694.8(H) ×1.2(D) mm |
| Uewerfläch | Antiglare (Haze 3%), Hard coating (2H) |
| Hellegkeet | 0 cd/m² |
| Kontrast Verhältnis | 1300:1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Min.)(CR≥10) |
| Display Modus | IPS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 6/9 (Typ.)(Tr/Td) |
| Glas Déift | - |
| transmissivitéit | 8.42% (Typ.)(with Polarizer) |
| weisen Faarwen | 16.7M 68% NTSC |
| Lampe Typ | No B/L |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Chauffeur ic | COF Built-in 6 source chips |
| Panel Gewiicht | 2.40/2.53Kgs (Typ./Max.) |
| Applikatioun | TV Sets |
| Signal Interface | EPI , 120 pins Connector |
| Input Volt | 12.7V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
