LC470WUN-SCA1

LC470WUN-SCA1
LC470WUN-SCA1 thumb
Mark
LG Display
Gréisst
47
Applikatioun
LCTV
Opléisung
1920×1080
Zesummesetzung
LCM
Hellegkeet
500
CR
1450:1
Faarwen
16.7M/1.06B
Backlight
EEFL
Interface
LVDS
In Stock
12024
Spezifikatioune

Part Number LC470WUN-SCA1
MarkLG Display
Gréisst47
ApplikatiounLCTV
Opléisung1920×1080
ZesummesetzungLCM
Hellegkeet500
CR1450:1
Faarwen16.7M/1.06B
GéigeliichtEEFL
InterfaceLVDS
Panel MarkLG Display
Panel ModellLC470WUN-SCA1
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst47 inch
Resolutioun1920(RGB)×1080 , FHD
Display ModusS-IPS, Normally Black, Transmissive
aktiv Beräich1039.68×584.82 mm
skizzéieren1096×640 mm
UewerflächAntiglare (Haze 10%), Hard coating (3H)
Hellegkeet500 cd/m² (Typ.)
Kontrast Verhältnis1450:1 (Typ.)
weisen Faarwen16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172%
Äntwert Zäit5 (Typ.)(G to G)
Vue Wénkel89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe TypEEFLEmbedded (Inverter)
Signal InterfaceLVDS (2 ch, 8/10-bit), 51 pins
Input Volt12.0V (Typ.)
ApplikatiounLCTV
Famill Modell
LC470WU1-SLA1 LG Display 47 1920×1080
LC470WUD-SCM1 LG Display 47 1920×1080
LC470WUE-SDP1 LG Display 47 1920×1080
LC470WUE-SEP1 LG Display 47 1920×1080
LC470WUF-SBF1 LG Display 47 1920×1080
LC470WUF-SCA2 LG Display 47 1920×1080
LC470WUF-SCA3 LG Display 47 1920×1080
LC470WUL-SBT1 LG Display 47 1920×1080
LC470WUN-SCA1 LG Display 47 1920×1080
LC470WUN-SDA1 LG Display 47 1920×1080
