| Part Number | LA123WF4-SR09 |
| Mark | LG Display |
| Gréisst | 12.3 |
| Applikatioun | Automotive Display |
| Opléisung | 1920×720 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | 8S6P |
| Interface | RSDS |
| Panel Mark | LG Display |
| Panel Modell | LA123WF4-SR09 |
| Panel Gréisst | 12.3" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 1920(RGB)×720, 167PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 292.032(W)×109.512(H) mm |
| bezel Ouverture | 296.03(W)×113.5(H) mm |
| Kontur Gréisst | 310(W)×128(H) ×10.75(D) mm |
| Uewerfläch | Antiglare, Antireflection |
| Hellegkeet | 600 cd/m² (Min.) |
| Kontrast Verhältnis | 800:1 (Min.) (TM) |
| Vue Wénkel | 89/89/89/89 (Min.)(CR≥10) |
| Display Modus | IPS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 30 (Max.)(G to G); 30 (Typ.)(MPRT) |
| weisen Faarwen | 16.7M 77% NTSC |
| Lampe Typ | 8S6P WLED , 10K hours , Without Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | - |
| Applikatioun | Automotive Display |
| Signal Interface | RSDS (2 Channel) , 110 pins FPC |
| Input Volt | 3.3/13.0V (Typ.)(VCC/VDD) |
| Ëmwelt | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
