| Part Number | LA090WH1-SL01 |
| Mark | LG Display |
| Gréisst | 9.0 |
| Applikatioun | Automotive Display |
| Opléisung | 1280×720 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | LG Display |
| Modell | LA090WH1-SL01 |
| diagonal Gréisst | 9.0 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1280(RGB)×720 [WXGA] 164PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 200.448(H)×106.056(V) mm |
| kontur dim. | 213.2(H)×121.2(V) ×8.6(D) mm |
| bezel Beräich | 203.148(H)×108.756(V) mm |
| Behandlung | Antiglare |
| luminance | 600 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 17/13 (Max.)(Tr/Td) |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥10) |
| Betribssystemer Modus | IPS, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 16.7M 65% NTSC |
| Liichtquell | WLED [6S3P] , 10K hours , W/O Driver |
| Gewiicht | 219/224g (Typ./Max.) |
| entworf fir | Automotive Display |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | LVDS (1 ch, 8-bit) , 60 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -40 ~ 95 °C |
| A090VW01 V3 | AUO | 9.0 | 800×480 |
| AT090TN10 | Innolux | 9.0 | 800×480 |
| CLAA090LC41CW | CPT | 9.0 | 800×480 |
| EE090NA-01C | Innolux | 9.0 | 1280×800 |
| G090VTN02.0 | AUO | 9.0 | 800×480 |
| HLD0909-020010 | Hosiden | 9.0 | 640×480 |
| HSD090ICW1-A00 | HannStar | 9.0 | 640×234 |
| LTL090CL01-W02 | Samsung | 9.0 | 1920×1280 |
| NL8048BC24-12 | NLT | 9.0 | 800×480 |
| TX23D85VM0BAA | KOE | 9.0 | 1280×768 |
