| Part Number | KB860DU15-L01 |
| Mark | BEST |
| Gréisst | 86 |
| Applikatioun | Digital Signage Outd |
| Opléisung | 3840×2160 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1200:1 |
| Faarwen | 1.07B |
| Géigeliicht | WLED |
| Interface | V-by-One |
| Mark | BEST |
| diagonal Gréisst | 86 inch |
| Pixel Format | 3840(RGB)×2160 [UHD] 51PPI |
| aktiv Beräich | 1895.04(H)×1065.96(V) mm |
| bezel Beräich | - |
| luminance | 1500 cd/m² (Typ.) |
| Vue Richtung | Symmetry |
| Vue Wénkel | 89/89/89/89 (Min.)(CR≥10) |
| Ënnerstëtzung Faarf | 1.07B 68% NTSC |
| Gewiicht | 55.0Kgs (Typ.) |
| Frame Taux | 60Hz |
| Interface Typ | V-by-One 8 lane , 51 pins Connector |
| Stroumversuergung | 12.0V (Typ.) |
| Ëmwelt | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Modell | KB860DU15-L01 |
| Typ | a-Si TFT-LCD , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 1930(H)×1105.5(V) mm |
| Behandlung | Antiglare (Haze 1%), Hard coating (2H) |
| Kontrast Verhältnis | 1200:1 (Typ.) (TM) |
| Äntwert Zäit | 8 (Typ.)(G to G) |
| Betribssystemer Modus | IPS, Normally Black, Transmissive |
| Liichtquell | WLED , 30K hours , With LED Driver |
| entworf fir | Digital Signage Outdoor High Brightness |
| Touch Panel | Without |
