| Part Number | JJ103IA-12A |
| Mark | Innolux |
| Gréisst | 10.3 |
| Applikatioun | Outdoor High Brightn |
| Opléisung | 1920×720 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1300:1 |
| Faarwen | 16.7M |
| Géigeliicht | 4 |
| Interface | LVDS |
| Panel Mark | Innolux |
| Panel Gréisst | 10.3" |
| Resolutioun | 1920(RGB)×720, 200PPI |
| Affichage Beräich | 243.648(W)×91.368(H) mm |
| Kontur Gréisst | 255.24(W)×106.68(H) mm |
| Hellegkeet | 800 cd/m² (Typ.) |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.7M 71% NTSC |
| Frequenz | 60Hz |
| Panel Gewiicht | 380g (Max.) |
| Signal Interface | LVDS (2 ch, 8-bit) , 50 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| Panel Modell | JJ103IA-12A |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | 246.65(W)×94.37(H) mm |
| Uewerfläch | Antiglare |
| Kontrast Verhältnis | 1300:1 (Typ.) (TM) |
| Display Modus | IPS, Normally Black, Transmissive |
| Äntwert Zäit | 27 (Typ.)(Tr+Td) |
| Lampe Typ | 4 strings WLED , 10K hours , Without Driver |
| Touchscreens | Without |
| Applikatioun | Outdoor High Brightness Automotive Display |
