| Part Number | ITSX98 |
| Mark | IDTech |
| Gréisst | 18.1 |
| Applikatioun | DMPC |
| Opléisung | 1280×1024 |
| Zesummesetzung | LCM |
| Hellegkeet | 270 |
| CR | 400:1 |
| Faarwen | 16.7M |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | IDTech |
| Panel Modell | ITSX98 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 18.1 inch |
| Resolutioun | 1280(RGB)×1024 , SXGA |
| Display Modus | DD-IPS, Normally Black, Transmissive |
| aktiv Beräich | 359.04×287.232 mm |
| skizzéieren | 389×317.2 mm |
| Uewerfläch | |
| Hellegkeet | 270 cd/m² (Typ.) |
| Kontrast Verhältnis | 400:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit) |
| Äntwert Zäit | 40 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 6 pcsCCFLWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | DMPC |
