| Part Number | HV650QUB-F9A |
| Mark | BOE |
| Gréisst | 65 |
| Applikatioun | TV Sets |
| Opléisung | 3840×2160 |
| Zesummesetzung | a-Si TFT-LCD, CELL |
| Hellegkeet | |
| CR | 1200:1 |
| Faarwen | 1.07B |
| Géigeliicht | No |
| Interface | V-by-One |
| Mark | BOE |
| Modell | HV650QUB-F9A |
| diagonal Gréisst | 65 inch |
| Typ | a-Si TFT-LCD, CELL |
| Pixel Format | 3840(RGB)×2160 [UHD] 68PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 1428.48(H)×803.52(V) mm |
| kontur dim. | 1438.48(H)×815.02(V) mm |
| bezel Beräich | - |
| Behandlung | Antiglare (Haze 1%) |
| luminance | 0 cd/m² |
| Kontrast Verhältnis | 1200:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 8 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Betribssystemer Modus | ADS, Normally Black, Transmissive |
| Plackedicke | 0.50+0.50 mm |
| Iwwerdroung | 5.1% (Typ.)(with Polarizer) |
| Ënnerstëtzung Faarf | 1.07B 99% sRGB |
| Liichtquell | No B/L |
| Gewiicht | TBD |
| entworf fir | TV Sets |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| d-ic detail | COF Built-in 12 source chips |
| Interface Typ | V-by-One 8 lane , 51 pins Connector |
| Stroumversuergung | 12.0V (Typ.) |
| Ëmwelt | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
