| Part Number | HV550QUB-F84 |
| Mark | BOE |
| Gréisst | 55 |
| Applikatioun | TV Sets |
| Opléisung | 3840×2160 |
| Zesummesetzung | a-Si TFT-LCD, CELL |
| Hellegkeet | |
| CR | 1200:1 |
| Faarwen | 1.07B |
| Géigeliicht | No |
| Interface | V-by-One |
| Panel Mark | BOE |
| Panel Modell | HV550QUB-F84 |
| Panel Gréisst | 55" |
| Panel Typ | a-Si TFT-LCD, CELL |
| Resolutioun | 3840(RGB)×2160, UHD, 80PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 1209.6(W)×680.4(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 1221.4(W)×694.8(H) ×1.3(D) mm |
| Uewerfläch | Antiglare (Haze 1%), Hard coating (3H) |
| Hellegkeet | 0 cd/m² |
| Kontrast Verhältnis | 1200:1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Display Modus | ADS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 8 (Typ.)(G to G) |
| Glas Déift | 0.50+0.50 mm |
| transmissivitéit | 5.5% (Typ.)(with Polarizer) |
| weisen Faarwen | 1.07B 73% NTSC |
| Lampe Typ | No B/L |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Chauffeur ic | COFBuilt-in 6 source chips |
| Panel Gewiicht | 2.70Kgs (Typ.) |
| Applikatioun | TV Sets |
| Signal Interface | V-by-One 8 lane , 51 pins Connector |
| Input Volt | 12.0V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| HV550QUB-B10 | BOE | 55 | 3840×2160 |
| LC550EQN-PGF1 | LG Display | 55 | 3840×2160 |
| LC550EUE-SER1 | LG Display | 55 | 1920×1080 |
| LC550WUD-SBM4 | LG Display | 55 | 1920×1080 |
| LTA550HJ19 | Samsung | 55 | 1920×1080 |
| LTA550HW04 | Samsung | 55 | 1920×1080 |
| ST5461B05-2 | CSOT | 55 | 1920×1080 |
| T550HVN01.3 CELL | AUO | 55 | 1920×1080 |
| T550QVN02.0 CELL | AUO | 55 | 3840×2160 |
| V546H1-LS1 | Innolux | 55 | 1920×1080 |
