| Part Number | HSD150GXN1-A00-C00 |
| Mark | HannStar |
| Gréisst | 15.0 |
| Applikatioun | Industrial |
| Opléisung | 1024×768 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 700:1 |
| Faarwen | 262K/16.2M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | HannStar |
| diagonal Gréisst | 15.0 inch |
| Pixel Format | 1024(RGB)×768 [XGA] 85PPI |
| aktiv Beräich | 304.128(H)×228.096(V) mm |
| bezel Beräich | 307.4(H)×231.3(V) mm |
| luminance | 250 cd/m² (Typ.) |
| Vue Richtung | - |
| Vue Wénkel | 80/80/60/80 (Typ.)(CR≥10) |
| Ënnerstëtzung Faarf | 262K/16.2M 60% NTSC |
| Gewiicht | 1.20Kgs (Max.) |
| Frame Taux | 60Hz |
| Interface Typ | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
| Modell | HSD150GXN1-A00-C00 |
| Typ | a-Si TFT-LCD , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 326.5(H)×253.5(V) ×12.7(D) mm |
| Behandlung | - |
| Kontrast Verhältnis | 700:1 (Typ.) (TM) |
| Äntwert Zäit | 12 (Typ.)(Tr+Td) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Liichtquell | WLED , 30K hours , With LED Driver |
| entworf fir | Industrial |
| Touch Panel | Embeded Touch |
| G150XTN01.0 | AUO | 15.0 | 1024×768 |
| G150XTN06.4 | AUO | 15.0 | 1024×768 |
| G150XVN01.0 | AUO | 15.0 | 1024×768 |
| HSD150PX16-A | HannStar | 15.0 | 1024×768 |
| LC150X01-A3K2 | LG Display | 15.0 | 1024×768 |
| LQ150X1LG92 | SHARP | 15.0 | 1024×768 |
| NL10276BC30-17 | NLT | 15.0 | 1024×768 |
| NL10276BC30-18C | NLT | 15.0 | 1024×768 |
| NL10276BC30-39 | NLT | 15.0 | 1024×768 |
| T150XG01 V2 | AUO | 15.0 | 1024×768 |
