| Part Number | HSD103JPW2-H10 |
| Mark | HannStar |
| Gréisst | 10.3 |
| Applikatioun | Outdoor High Brightn |
| Opléisung | 1920×720 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 1500:1 |
| Faarwen | 16.7M |
| Géigeliicht | 4 strings WLED , 20K hours , No Driver |
| Interface | LVDS |
| Fabrikant beschwéiert | HannStar |
| Écran Gréisst | 10.3 inch |
| Pixel Zuel | 1920(RGB)×720 200PPI |
| aktiv Beräich (mm) | 243.648 × 91.368 (H×V) |
| Bezel Beräich (mm) | 246.7 × 94.4 (H×V) |
| luminance | 1000 cd/m² (Typ.) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| gutt Vue op | Symmetry |
| Faarfdéift | 16.7M 70% NTSC |
| mass | TBD |
| Erfrëschungsrate | 60Hz |
| Signal Typ | LVDS (2 ch, 8-bit) , 60 pins FPC |
| Spannungsversuergung | 3.3V (Typ.) |
| max. Bewäertungen | Storage Temp.: -40 ~ 95 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| Modell Numm | HSD103JPW2-H10 |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 258.8 × 110 × 17 (H×V×D) |
| Behandlung | Antiglare, Hard coating (3H) |
| Kontrast Verhältnis | 1500 : 1 (Typ.) (TM) |
| Äntwert | 30 (Max.)(Tr+Td) ms |
| Aarbecht Modus | IPS Pro, Normally Black, Transmissive |
| benotzt fir | Outdoor High Brightness Automotive Display |
| touchscreen | Without |
