| Part Number | HSD101BFW6-A00 |
| Mark | HannStar |
| Gréisst | 10.1 |
| Applikatioun | Pad & Tablet |
| Opléisung | 1024×600 |
| Zesummesetzung | CELL, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | No B/L |
| Interface | |
| Fabrikant beschwéiert | HannStar |
| Modell Numm | HSD101BFW6-A00 |
| Écran Gréisst | 10.1 inch |
| Écran Typ | CELL, a-Si TFT-LCD |
| Pixel Zuel | 1024(RGB)×600 (WSVGA) 117PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 222.72 × 125.28 (H×V) |
| Kontur (mm) | 230.4 × 134.2 × 0.8 (H×V×D) |
| luminance | 0 cd/m² |
| Kontrast Verhältnis | 800 : 1 (Typ.) (TM) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Äntwert | 10/20 (Typ.)(Tr/Td) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | IPS Pro, Normally Black, Transmissive |
| Glas deck | 0.40+0.40 mm |
| transmissivitéit | 5.81% (Typ.)(with Polarizer) |
| Faarfdéift | 16.7M 45% NTSC |
| mass | - |
| benotzt fir | Pad & Tablet |
| Erfrëschungsrate | - |
| touchscreen | Without |
| Chauffer ic Lëscht | Suggest COG EK79007AD, HX8282-C, EK73215BCGA, HX8696-A |
| max. Bewäertungen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
