| Part Number | HR270WU1-200 |
| Mark | BOE |
| Gréisst | 27.0 |
| Applikatioun | DMPC |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM |
| Hellegkeet | 700 |
| CR | 1000:1 |
| Faarwen | 1.07B |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | BOE |
| Panel Modell | HR270WU1-200 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 27.0 inch |
| Resolutioun | 1920(RGB)×1080 , FHD |
| Display Modus | AFFS, Normally Black, Transmissive |
| aktiv Beräich | 597.888×336.312 mm |
| skizzéieren | 630×368.2×15.7 mm |
| Uewerfläch | Antiglare (Haze 25%), Hard coating (3H) |
| Hellegkeet | 700 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 1.07B (10-bit), sRGB |
| Äntwert Zäit | 14 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDWithout Driver |
| Signal Interface | LVDS (2 ch, 10-bit), 51 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | DMPC |
