| Part Number | HN116WXA-200 |
| Mark | BOE |
| Gréisst | 11.6 |
| Applikatioun | Laptop |
| Opléisung | 1366×768 |
| Zesummesetzung | a-Si TFT-LCD, Assemb |
| Hellegkeet | |
| CR | 600:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | eDP |
| Mark | BOE |
| Modell | HN116WXA-200 (BOE064A) |
| diagonal Gréisst | 11.6 inch |
| Typ | a-Si TFT-LCD, Assembly |
| Pixel Format | 1366(RGB)×768 [WXGA] 135PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 256.125(H)×144(V) mm |
| kontur dim. | 293.3(H)×183(V) ×4(D) mm |
| bezel Beräich | - |
| Behandlung | Hard coating (7H) |
| luminance | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 600:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 28 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Betribssystemer Modus | ADS, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 262K 60% NTSC |
| Liichtquell | WLED [9S4P] , 15K hours , With LED Driver |
| Form Stil | - |
| entworf fir | Laptop |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | eDP (2 Lanes) , eDP1.2 , 30 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
