| Part Number | H546DLK01.0 |
| Mark | AUO |
| Gréisst | 5.5 |
| Applikatioun | Mobile Phone |
| Opléisung | 1080×1920 |
| Zesummesetzung | AM-OLED , OLED |
| Hellegkeet | |
| CR | 10000:1 |
| Faarwen | 16.7M |
| Géigeliicht | self |
| Interface | MIPI |
| Panel Mark | AUO |
| Panel Gréisst | 5.5" |
| Resolutioun | 1080(RGB)×1920, FHD, 403PPI |
| Affichage Beräich | 68.04(W)×120.96(H) mm |
| Kontur Gréisst | 70.84(W)×128.01(H) ×0.92(D) mm |
| Hellegkeet | 350 cd/m² (Typ.) |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥1600) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.7M 100% NTSC |
| Frequenz | 100Hz |
| Chauffeur ic | COG Built-in RM69071 |
| Panel Gewiicht | - |
| Signal Interface | MIPI (4 data lanes) |
| Input Volt | 1.8/3.1/5.8/4.6/-2.9V (Typ.)(IOVCC/VCI/AVDD/OVDD/OVSS) |
| Ëmwelt | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| Panel Modell | H546DLK01.0 |
| Panel Typ | AM-OLED , OLED |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | Hard coating (3H) |
| Kontrast Verhältnis | 10000:1 (Min.) (TM) |
| Display Modus | - |
| Äntwert Zäit | - |
| Lampe Typ | self |
| Touchscreens | Embeded Touch |
| Applikatioun | Mobile Phone |
