| Part Number | GV101WXM-N81 |
| Mark | BOE |
| Gréisst | 10.1 |
| Applikatioun | Pad & Tablet Industr |
| Opléisung | 1280×800 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | |
| Panel Mark | BOE |
| Panel Gréisst | 10.1" |
| Resolutioun | 1280(RGB)×800, WXGA, 149PPI |
| Affichage Beräich | 216.96(W)×135.6(H) mm |
| Kontur Gréisst | 228.3(W)×149.05(H) ×2.6(D) mm |
| Hellegkeet | 300 cd/m² (Typ.) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.7M 48% NTSC |
| Frequenz | 60Hz |
| Gewiicht | 155g (Max.) |
| Panel Modell | GV101WXM-N81 (BOE03F2) |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | Glare (Haze 0%), Hard coating |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Display Modus | ADS, Normally Black, Transmissive |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Lampe Typ | WLED , 15K hours , With LED Driver |
| Touchscreens | Without |
| Applikatioun | Pad & Tablet Industrial |
| A101VW01 V0 | AUO | 10.1 | 800×480 |
| B101AW01 V0 HW5A | AUO | 10.1 | 1024×576 |
| B101EAN01.3 | AUO | 10.1 | 1280×800 |
| B101EAN01.5 | AUO | 10.1 | 1280×800 |
| B101UAN01.1 | AUO | 10.1 | 1920×1200 |
| CLAA101NA0ACN | CPT | 10.1 | 1024×576 |
| HSD101PWW1-A00 Rev.4 | HannStar | 10.1 | 1280×800 |
| LP101WH4-SLA6 | LG Display | 10.1 | 1366×768 |
| LTL101AL01-W01 | Samsung | 10.1 | 1280×800 |
| LTL101AL06-W14 | Samsung | 10.1 | 1280×800 |
