| Part Number | G238HAN01.1 |
| Mark | AUO |
| Gréisst | 23.8 |
| Applikatioun | Industrial Medical I |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | 18S4P WLED , 50K hours , No Driver |
| Interface | LVDS |
| Fabrikant beschwéiert | AUO |
| Écran Gréisst | 23.8 inch |
| Pixel Zuel | 1920(RGB)×1080 (FHD) 92PPI |
| aktiv Beräich (mm) | 527.04 × 296.46 (H×V) |
| Bezel Beräich (mm) | 530.2 × 299.6 (H×V) |
| luminance | 400 cd/m² (Typ.) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| gutt Vue op | Symmetry |
| Faarfdéift | 16.7M 70% NTSC |
| mass | 2.30Kgs (Typ.) |
| Erfrëschungsrate | 60Hz |
| Signal Typ | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Spannungsversuergung | 5.0V (Typ.) |
| max. Bewäertungen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Modell Numm | G238HAN01.1 |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 543 × 317.4 × 11.65 (H×V×D) |
| Behandlung | Antiglare, Hard coating (3H) |
| Kontrast Verhältnis | 1000 : 1 (Typ.) (TM) |
| Äntwert | 14 (Typ.)(G to G) ms |
| Aarbecht Modus | AHVA, Normally Black, Transmissive |
| benotzt fir | Industrial Medical Imaging |
| touchscreen | Without |
