| Part Number | G229HAN01.0 |
| Mark | AUO |
| Gréisst | 22.9 |
| Applikatioun | Industrial Stretched |
| Opléisung | 1920×165 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | |
| Panel Mark | AUO |
| Panel Gréisst | 22.9" |
| Resolutioun | 1920(RGB)×165, 84PPI |
| Affichage Beräich | 578.88(W)×49.7475(H) mm |
| Kontur Gréisst | 587.08(W)×62.05(H) ×10.71(D) mm |
| Hellegkeet | 500 cd/m² (Typ.) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.7M 72% NTSC |
| Frequenz | 60Hz |
| Gewiicht | 460g (Typ.) |
| Panel Modell | G229HAN01.0 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | 580.88(W)×51.75(H) mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Display Modus | AHVA, Normally Black, Transmissive |
| Äntwert Zäit | 13/12 (Typ.)(Tr/Td) |
| Lampe Typ | WLED , 70K hours , With LED Driver |
| Touchscreens | Without |
| Applikatioun | Industrial Stretched Bar LCD |
