| Part Number | G190EG02 V104 |
| Mark | AUO |
| Gréisst | 19.0 |
| Applikatioun | Industrial Medical I |
| Opléisung | 1280×1024 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 2000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED , 50K hours , With LED Driver |
| Interface | LVDS |
| Fabrikant beschwéiert | AUO |
| Écran Gréisst | 19.0 inch |
| Pixel Zuel | 1280(RGB)×1024 (SXGA) 86PPI |
| aktiv Beräich (mm) | 376.32 × 301.056 (H×V) |
| Bezel Beräich (mm) | 380.32 × 305.06 (H×V) |
| luminance | 350 cd/m² (Typ.) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| gutt Vue op | Symmetry |
| Faarfdéift | 16.7M 70% NTSC |
| mass | 1.74Kgs (Typ.) |
| Erfrëschungsrate | 60Hz |
| Signal Typ | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Spannungsversuergung | 5.0V (Typ.) |
| max. Bewäertungen | Storage Temp.: -20 ~ 70 °C Operating Temp.: -15 ~ 70 °C |
| Modell Numm | G190EG02 V104 |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 396 × 324 × 15.8 (H×V×D) |
| Behandlung | Antiglare |
| Kontrast Verhältnis | 2000 : 1 (Typ.) (TM) |
| Äntwert | 15/5 (Typ.)(Tr/Td) ms |
| Aarbecht Modus | MVA, Normally Black, Transmissive |
| benotzt fir | Industrial Medical Imaging |
| touchscreen | Without |
