| Part Number | G156XTT03.0 |
| Mark | AUO |
| Gréisst | 15.6 |
| Applikatioun | Industrial |
| Opléisung | 1366×768 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 16.2M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | AUO |
| Modell | G156XTT03.0 |
| diagonal Gréisst | 15.6 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1366(RGB)×768 [WXGA] 100PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 344.232(H)×193.536(V) mm |
| kontur dim. | - |
| bezel Beräich | - |
| Behandlung | Hard coating (7H) |
| luminance | - |
| Kontrast Verhältnis | 500:1 (Typ.) (TM) |
| Vue Richtung | - |
| Äntwert Zäit | 6/2 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| Vue Wénkel | 85/85/80/80 (Typ.)(CR≥10) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Ënnerstëtzung Faarf | 16.2M |
| Liichtquell | WLED , 50K hours , With LED Driver |
| Gewiicht | - |
| entworf fir | Industrial |
| Frame Taux | 60Hz |
| Touch Panel | PCAP |
| Interface Typ | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Stroumversuergung | 5.0V (Typ.) |
