| Part Number | G156HAN02.1 |
| Mark | AUO |
| Gréisst | 15.6 |
| Applikatioun | Industrial Medical I |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED , 50K hours , With LED Driver |
| Interface | LVDS |
| Fabrikant beschwéiert | AUO |
| Écran Gréisst | 15.6 inch |
| Pixel Zuel | 1920(RGB)×1080 (FHD) 141PPI |
| aktiv Beräich (mm) | 344.16 × 193.59 (H×V) |
| Bezel Beräich (mm) | 347.06 × 196.49 (H×V) |
| luminance | 500 cd/m² (Typ.) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| gutt Vue op | Symmetry |
| Faarfdéift | 16.7M 99% sRGB |
| mass | 600/660g (Typ./Max.) |
| Erfrëschungsrate | 60Hz |
| Signal Typ | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Spannungsversuergung | 3.3V (Typ.) |
| max. Bewäertungen | Storage Temp.: -20 ~ 70 °C Operating Temp.: -20 ~ 70 °C |
| Modell Numm | G156HAN02.1 |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 363.8 × 215.9 × 9.3 (H×V×D) |
| Behandlung | Antiglare, Hard coating (3H) |
| Kontrast Verhältnis | 1000 : 1 (Typ.) (TM) |
| Äntwert | 25 (Typ.)(Tr+Td) ms |
| Aarbecht Modus | AHVA, Normally Black, Transmissive |
| benotzt fir | Industrial Medical Imaging |
| touchscreen | Without |
| AC156GA01 | Mitsubishi | 15.6 | 1366×768 |
| B156HAN01.2 | AUO | 15.6 | 1920×1080 |
| B156HTB01.0 | AUO | 15.6 | 1920×1080 |
| B156HW01 V1 | AUO | 15.6 | 1920×1080 |
| G156HAN01.0 | AUO | 15.6 | 1920×1080 |
| G156HTD01.0 | AUO | 15.6 | 1920×1080 |
| G156HTN01.0 | AUO | 15.6 | 1920×1080 |
| G156HTN02.0 | AUO | 15.6 | 1920×1080 |
| G156HTN02.1 | AUO | 15.6 | 1920×1080 |
| LTN156AT01-H01 | Samsung | 15.6 | 1366×768 |
