| Part Number | G156HAB01.0 |
| Mark | AUO |
| Gréisst | 15.6 |
| Applikatioun | Industrial |
| Opléisung | 1920×1080 |
| Zesummesetzung | a-Si TFT-LCD , Assem |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.2M |
| Géigeliicht | WLED |
| Interface | eDP |
| Panel Mark | AUO |
| Panel Gréisst | 15.6" |
| Resolutioun | 1920(RGB)×1080, FHD, 141PPI |
| Affichage Beräich | 344.16(W)×193.59(H) mm |
| Kontur Gréisst | 361(W)×227(H) ×4.9(D) mm |
| Hellegkeet | 300 cd/m² (Typ.) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.2M 45% NTSC |
| Frequenz | 60Hz |
| Panel Gewiicht | 620g (Max.) |
| Signal Interface | eDP (2 Lanes) , eDP1.2 , 40 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Panel Modell | G156HAB01.0 |
| Panel Typ | a-Si TFT-LCD , Assembly |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | Hard coating (7H) |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Display Modus | - |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Lampe Typ | WLED , 30K hours , With LED Driver |
| Touchscreens | On-Cell Touch |
| Applikatioun | Industrial |
