| Part Number | G150XTN06.B |
| Mark | AUO |
| Gréisst | 15.0 |
| Applikatioun | Industrial Outdoor H |
| Opléisung | 1024×768 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 262K/16.2M |
| Géigeliicht | WLED , 50K hours , With LED Driver |
| Interface | |
| Fabrikant beschwéiert | AUO |
| Écran Gréisst | 15.0 inch |
| Pixel Zuel | 1024(RGB)×768 (XGA) 85PPI |
| aktiv Beräich (mm) | 304.128 × 228.096 (H×V) |
| Bezel Beräich (mm) | 311.9 × 236.85 (H×V) |
| luminance | 800 (Typ.)(cd/m²) |
| Vue Wénkel | 80/80/70/80 (Typ.)(CR≥10) |
| gutt Vue op | - |
| Faarfdéift | 262K/16.2M 60% NTSC |
| mass | 1.00Kgs (Max.) |
| Erfrëschungsrate | 60Hz |
| Modell Numm | G150XTN06.B |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 326.5 × 253.5 × 10 (H×V×D) |
| Behandlung | Antireflection |
| Kontrast Verhältnis | 800 : 1 (Typ.) (TM) |
| Aarbecht Modus | TN, Normally White, Transmissive |
| Äntwert | 5.7/2.3 (Typ.)(Tr/Td) ms |
| benotzt fir | Industrial Outdoor High Brightness |
| touchscreen | Without |
| G150XG01 V0 | AUO | 15.0 | 1024×768 |
| G150XG01 V3 | AUO | 15.0 | 1024×768 |
| G150XG01 V4 | AUO | 15.0 | 1024×768 |
| G150XGE-L05 | Innolux | 15.0 | 1024×768 |
| G150XTN01.0 | AUO | 15.0 | 1024×768 |
| G150XTN02.0 | AUO | 15.0 | 1024×768 |
| G150XTN03.0 | AUO | 15.0 | 1024×768 |
| G150XTN05.0 | AUO | 15.0 | 1024×768 |
| G150XTN06.2 | AUO | 15.0 | 1024×768 |
| G150XVN01.0 | AUO | 15.0 | 1024×768 |
