| Part Number | G150XTN06.9 |
| Mark | AUO |
| Gréisst | 15.0 |
| Applikatioun | Industrial Outdoor H |
| Opléisung | 1024×768 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 262K/16.2M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | AUO |
| Modell | G150XTN06.9 |
| diagonal Gréisst | 15.0 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1024(RGB)×768 [XGA] 85PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 304.128(H)×228.096(V) mm |
| kontur dim. | 326.5(H)×253.5(V) ×10(D) mm |
| bezel Beräich | 311.9(H)×236.85(V) mm |
| Behandlung | Antiglare |
| luminance | 1600 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Vue Richtung | - |
| Äntwert Zäit | 5.7/2.3 (Typ.)(Tr/Td) |
| Vue Wénkel | 80/80/70/80 (Typ.)(CR≥10) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Ënnerstëtzung Faarf | 262K/16.2M 60% NTSC |
| Liichtquell | WLED , 50K hours , With LED Driver |
| Gewiicht | 1.00Kgs (Max.) |
| entworf fir | Industrial Outdoor High Brightness |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -30 ~ 70 °C ; Storage Temperature: -30 ~ 70 °C |
