| Part Number | G150XTN03.7 |
| Mark | AUO |
| Gréisst | 15.0 |
| Applikatioun | Industrial |
| Opléisung | 1024×768 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 262K/16.2M |
| Géigeliicht | WLED |
| Interface | |
| Panel Mark | AUO |
| Panel Gréisst | 15.0" |
| Resolutioun | 1024(RGB)×768, XGA, 85PPI |
| Affichage Beräich | 304.128(W)×228.096(H) mm |
| Kontur Gréisst | 326.5(W)×253.5(H) ×10(D) mm |
| Hellegkeet | 250 cd/m² (Typ.) |
| Vue Wénkel | 45/45/20/40 (Typ.)(CR≥10) |
| beschte Vue op | - |
| weisen Faarwen | 262K/16.2M 60% NTSC |
| Frequenz | 60Hz |
| Gewiicht | 1.02Kgs (Max.) |
| Panel Modell | G150XTN03.7 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | 313.55(W)×237.25(H) mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Kontrast Verhältnis | 500:1 (Typ.) (TM) |
| Display Modus | TN, Normally White, Transmissive |
| Äntwert Zäit | 6/2 (Typ.)(Tr/Td) |
| Lampe Typ | WLED , 50K hours , With LED Driver |
| Touchscreens | Without |
| Applikatioun | Industrial |
