| Part Number | G133XTN01.0 |
| Mark | AUO |
| Gréisst | 13.3 |
| Applikatioun | Industrial |
| Opléisung | 1366×768 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 400:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | AUO |
| Panel Gréisst | 13.3" |
| Resolutioun | 1366(RGB)×768, WXGA, 118PPI |
| Affichage Beräich | 293.42(W)×164.97(H) mm |
| Kontur Gréisst | 306.3(W)×197.2(H) mm |
| Hellegkeet | 300 cd/m² (Typ.) |
| Vue Wénkel | 70/70/50/60 (Typ.)(CR≥10) |
| beschte Vue op | - |
| weisen Faarwen | 16.7M 45% NTSC |
| Frequenz | 60Hz |
| Panel Gewiicht | 255g (Max.) |
| Signal Interface | LVDS (1 ch, 8-bit) , 40 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
| Panel Modell | G133XTN01.0 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Kontrast Verhältnis | 400:1 (Typ.) (TM) |
| Display Modus | TN, Normally White, Transmissive |
| Äntwert Zäit | 5.7/2.3 (Typ.)(Tr/Td) |
| Lampe Typ | WLED , 20K hours , With LED Driver |
| Touchscreens | Without |
| Applikatioun | Industrial |
