| Part Number | G104STN01.4 |
| Mark | AUO |
| Gréisst | 10.4 |
| Applikatioun | Industrial |
| Opléisung | 800×600 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 700:1 |
| Faarwen | 262K/16.2M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | AUO |
| Modell | G104STN01.4 |
| diagonal Gréisst | 10.4 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 800(RGB)×600 [SVGA] 96PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 211.2(H)×158.4(V) mm |
| kontur dim. | - |
| luminance | - |
| Kontrast Verhältnis | 700:1 (Typ.) (TM) |
| Vue Richtung | - |
| Äntwert Zäit | - |
| Vue Wénkel | 80/80/60/70 (Typ.)(CR≥10) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Ënnerstëtzung Faarf | 262K/16.2M |
| Liichtquell | WLED |
| Gewiicht | - |
| entworf fir | Industrial |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | LVDS (1 ch, 6/8-bit) |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
