| Part Number | G101STN01.5 |
| Mark | AUO |
| Gréisst | 10.1 |
| Applikatioun | Industrial |
| Opléisung | 1024×600 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | WLED |
| Interface | Parallel |
| Mark | AUO |
| diagonal Gréisst | 10.1 inch |
| Pixel Format | 1024(RGB)×600 [WSVGA] 117PPI |
| aktiv Beräich | 222.72(H)×125.28(V) mm |
| bezel Beräich | 226.43(H)×128.1(V) mm |
| luminance | 350 cd/m² (Typ.) |
| Vue Richtung | - |
| Vue Wénkel | 70/70/60/60 (Typ.)(CR≥10) |
| Ënnerstëtzung Faarf | 262K/16.7M 45% NTSC |
| Gewiicht | 340g (Max.) |
| Frame Taux | 60Hz |
| Interface Typ | Parallel RGB (1 ch, 6/8-bit) , 50 pins FPC |
| Stroumversuergung | 3.3/10/18/-8V (Typ.)(VDD/AVDD/VGH/VGL) |
| Ëmwelt | Operating Temperature: -10 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| Modell | G101STN01.5 |
| Typ | a-Si TFT-LCD , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 235(H)×143(V) ×5.5(D) mm |
| Behandlung | Antiglare, Hard coating (3H) |
| Kontrast Verhältnis | 500:1 (Typ.) (TM) |
| Äntwert Zäit | 7/9 (Typ.)(Tr/Td) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Liichtquell | WLED , 15K hours , W/O Driver |
| entworf fir | Industrial |
| Touch Panel | Without |
