| Part Number | G101EAN02.1 |
| Mark | AUO |
| Gréisst | 10.1 |
| Applikatioun | Industrial |
| Opléisung | 1280×800 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | AUO |
| diagonal Gréisst | 10.1 inch |
| Pixel Format | 1280(RGB)×800 [WXGA] 149PPI |
| aktiv Beräich | 216.96(H)×135.6(V) mm |
| bezel Beräich | - |
| luminance | 400 cd/m² (Typ.) |
| Vue Richtung | Symmetry |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Ënnerstëtzung Faarf | 16.7M 50% NTSC |
| Gewiicht | 195g (Max.) |
| Frame Taux | 60Hz |
| Interface Typ | LVDS (1 ch, 8-bit) , 40 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
| Modell | G101EAN02.1 |
| Typ | a-Si TFT-LCD , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 227.72(H)×147.8(V) ×4.8(D) mm |
| Behandlung | Hard coating |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Äntwert Zäit | 29 (Typ.)(Tr+Td) |
| Betribssystemer Modus | AHVA, Normally Black, Transmissive |
| Liichtquell | WLED , 30K hours , With LED Driver |
| entworf fir | Industrial |
| Touch Panel | Without |
