| Part Number | G080UAN01.0 |
| Mark | AUO |
| Gréisst | 8.0 |
| Applikatioun | Industrial |
| Opléisung | 1200×1920 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | 8S3P |
| Interface | |
| Panel Mark | AUO |
| Panel Gréisst | 8.0" |
| Resolutioun | 1200(RGB)×1920, WUXGA, 283PPI |
| Affichage Beräich | 107.64(W)×172.224(H) mm |
| Kontur Gréisst | 114.6(W)×184.13(H) ×3.95(D) mm |
| Hellegkeet | 500 cd/m² (Typ.) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.7M 60% NTSC |
| Frequenz | 60Hz |
| Gewiicht | 80g (Max.) |
| Panel Modell | G080UAN01.0 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | Glare (Haze 0%) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Display Modus | AHVA, Normally Black, Transmissive |
| Äntwert Zäit | 27 (Typ.)(Tr+Tf) |
| Lampe Typ | 8S3P WLED , 20K hours , Without Driver |
| Touchscreens | Without |
| Applikatioun | Industrial |
