| Part Number | G070VAN01.0 |
| Mark | AUO |
| Gréisst | 7.0 |
| Applikatioun | Industrial |
| Opléisung | 800×480 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1300:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | AUO |
| Modell | G070VAN01.0 |
| diagonal Gréisst | 7.0 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 800×480(RGB) [WVGA] 133PPI |
| Configuratioun | RGB Horizontal Stripe |
| aktiv Beräich | 152.4(H)×91.44(V) mm |
| kontur dim. | 166.6(H)×107(V) ×10(D) mm |
| bezel Beräich | 154.2(H)×93.24(V) mm |
| Behandlung | Antiglare |
| luminance | 480 cd/m² (Typ.) |
| Kontrast Verhältnis | 1300:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 11/19 (Max.)(Tr/Td) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Betribssystemer Modus | AHVA, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 262K/16.7M 70% NTSC |
| Liichtquell | WLED [7S2P] , 50K hours , W/O Driver |
| Gewiicht | 175±10%g |
| entworf fir | Industrial |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
