| Part Number | F101NWN7 R0 |
| Mark | IVO |
| Gréisst | 10.1 |
| Applikatioun | Pad & Tablet |
| Opléisung | 1920×1200 |
| Zesummesetzung | a-Si TFT-LCD, CELL |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 60% |
| Géigeliicht | No |
| Interface | |
| Panel Mark | IVO |
| Panel Modell | F101NWN7 R0 |
| Panel Gréisst | 10.1" |
| Panel Typ | a-Si TFT-LCD, CELL |
| Resolutioun | 1920(RGB)×1200, WUXGA, 224PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 217.44(W)×135.9(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 225.5(W)×144.4(H) ×0.4(D) mm |
| Uewerfläch | - |
| Hellegkeet | 0 cd/m² |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Vue Wénkel | 88/88/88/88 (Typ.)(CR≥10) |
| Display Modus | IPS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 65/45 (Max.)(Tr/Td) |
| Glas Déift | 0.20+0.20 mm |
| transmissivitéit | 3.8% (Typ.)(with Polarizer) |
| weisen Faarwen | 60% NTSC |
| Lampe Typ | No B/L |
| Frequenz | - |
| Touchscreens | Without |
| Panel Gewiicht | 56.1g (Max.) |
| Applikatioun | Pad & Tablet |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
