| Part Number | EV121WXM-N12 |
| Mark | BOE |
| Gréisst | 12.1 |
| Applikatioun | Medical Imaging |
| Opléisung | 1280×800 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1200:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | BOE |
| Modell | EV121WXM-N12 |
| diagonal Gréisst | 12.1 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1280(RGB)×800 [WXGA] 124PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 261.12(H)×163.2(V) mm |
| kontur dim. | 277.7(H)×180.6(V) ×9.2(D) mm |
| bezel Beräich | 264.12(H)×166.2(V) mm |
| Behandlung | Antiglare (Haze 25%) |
| luminance | 500 cd/m² (Typ.) |
| Kontrast Verhältnis | 1200:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Betribssystemer Modus | ADS, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 262K/16.7M 100% sRGB |
| Liichtquell | WLED [12S4P] , 50K hours , With LED Driver |
| Gewiicht | TBD |
| entworf fir | Medical Imaging |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
