| Part Number | ETM057010EDHU |
| Mark | EDT |
| Gréisst | 5.7 |
| Applikatioun | Industrial |
| Opléisung | 640×480 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 350:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | Parallel |
| Panel Mark | EDT |
| Panel Modell | ETM057010EDHU |
| Panel Gréisst | 5.7" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 640(RGB)×480, VGA, 141PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 115.2(W)×86.4(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 147.6(W)×100(H) ×11.7(D) mm |
| Uewerfläch | - |
| Hellegkeet | 380 cd/m² (Typ.) |
| Kontrast Verhältnis | 350:1 (Typ.) (TM) |
| Vue Wénkel | 65/65/55/52 (Typ.)(CR≥10) |
| Display Modus | TN, Normally White, Transmissive |
| beschte Vue op | 12 o'clock |
| Äntwert Zäit | 15/35 (Typ.)(Tr/Td) |
| weisen Faarwen | 16.7M 51% NTSC |
| Lampe Typ | WLED , 30K hours , With LED Driver |
| Frequenz | 60Hz |
| Touchscreens | PCAP |
| Panel Gewiicht | - |
| Applikatioun | Industrial |
| Signal Interface | Parallel RGB (1 ch, 8-bit) , 40 pins Connector |
| Input Volt | 3.3/3.3V (Typ.)(VCC/VDD) |
| Ëmwelt | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
