| Part Number | ET104S0M-N11 |
| Mark | BOE |
| Gréisst | 10.4 |
| Applikatioun | Industrial |
| Opléisung | 800×600 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 262K/16.2M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | BOE |
| diagonal Gréisst | 10.4 inch |
| Pixel Format | 800(RGB)×600 [SVGA] 96PPI |
| aktiv Beräich | 211.2(H)×158.4(V) mm |
| bezel Beräich | 215(H)×162(V) mm |
| luminance | 350 cd/m² (Typ.) |
| Vue Richtung | 12 o'clock |
| Vue Wénkel | 80/80/65/75 (Typ.)(CR≥10) |
| Ënnerstëtzung Faarf | 262K/16.2M 55% NTSC |
| Gewiicht | 288g (Typ.) |
| Frame Taux | 60Hz |
| Interface Typ | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| Modell | ET104S0M-N11 |
| Typ | a-Si TFT-LCD , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 236(H)×176.9(V) ×5.9(D) mm |
| Behandlung | Antiglare (Haze 25%) |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Liichtquell | WLED , 30K hours , W/O Driver |
| entworf fir | Industrial |
| Touch Panel | Without |
