| Part Number | EMA-101201 |
| Mark | eMagin |
| Gréisst | 0.63 |
| Applikatioun | HMD VR AR |
| Opléisung | 1280×1024 |
| Zesummesetzung | Si-OLED, OLED |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | Grayscale |
| Géigeliicht | self |
| Interface | LVDS |
| Mark | eMagin |
| Modell | EMA-101201 |
| diagonal Gréisst | 0.63 inch |
| Typ | Si-OLED, OLED |
| Pixel Format | 1280(LCR)×1024 [SXGA] 2619PPI |
| Configuratioun | LCR Vertical Stripe |
| aktiv Beräich | 12.4(H)×9.945(V) mm |
| kontur dim. | 19.5(H)×14.8(V) ×5.4(D) mm |
| luminance | 900 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | - |
| Vue Wénkel | - |
| Betribssystemer Modus | - |
| Ënnerstëtzung Faarf | Grayscale 52% NTSC |
| Liichtquell | self |
| Gewiicht | 3.00g (Typ.) |
| entworf fir | HMD VR AR |
| Frame Taux | - |
| Touch Panel | Without |
| Interface Typ | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Stroumversuergung | 5/1.8/-1.5V (Typ.)(VDC/VDD/VPG) |
| Ëmwelt | Operating Temperature: -45 ~ 70 °C ; Storage Temperature: -55 ~ 90 °C |
