| Part Number | EL160.120.39-SPI |
| Mark | Lumineq |
| Gréisst | 3.1 |
| Applikatioun | Industrial |
| Opléisung | 160×120 |
| Zesummesetzung | EL, EL |
| Hellegkeet | |
| CR | 60:1 |
| Faarwen | Mono(Yellow) |
| Géigeliicht | self |
| Interface | SPI |
| Mark | Lumineq |
| Modell | EL160.120.39-SPI |
| diagonal Gréisst | 3.1 inch |
| Typ | EL, EL |
| Pixel Format | 160×120 [QQVGA] 65PPI |
| Configuratioun | Rectangle |
| aktiv Beräich | 62.3(H)×46.7(V) mm |
| kontur dim. | 93.6(H)×61.5(V) mm |
| luminance | 70 cd/m² (Typ.) |
| Kontrast Verhältnis | 60:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 1 (Max.) |
| Vue Wénkel | 89/89/89/89 (Typ.) |
| Betribssystemer Modus | - |
| Ënnerstëtzung Faarf | Mono(Yellow) |
| Liichtquell | self , 50K hours |
| Gewiicht | 65.0g |
| entworf fir | Industrial |
| Frame Taux | 150Hz |
| Touch Panel | Without |
| Interface Typ | SPI , 20 pins Connector |
| Stroumversuergung | 5.25/18V (Typ.)(VL/VH) |
| Ëmwelt | Operating Temperature: -50 ~ 70 °C ; Storage Temperature: -60 ~ 105 °C ; Vibration Level: 3.16G (31.0 m/s²) |
