| Part Number | E1414AK68.A |
| Mark | EDO |
| Gréisst | 1.4 |
| Applikatioun | Wearable |
| Opléisung | 320×360 |
| Zesummesetzung | OLED, AM-OLED |
| Hellegkeet | |
| CR | 10000:1 |
| Faarwen | 16.7M |
| Géigeliicht | self |
| Interface | MIPI |
| Fabrikant beschwéiert | EDO |
| Modell Numm | E1414AK68.A |
| Écran Gréisst | 1.4 inch |
| Écran Typ | OLED, AM-OLED |
| Pixel Zuel | 320(RGB)×360 340PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 23.84 × 26.82 (H×V) |
| Kontur (mm) | 26.04 × 31.78 × 0.85 (H×V×D) |
| luminance | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 10000 : 1 (Min.) (TM) |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥1000) |
| Äntwert | 2 (Typ.)(Tr+Tf) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | - |
| Faarfdéift | 16.7M 105% NTSC |
| mass | - |
| benotzt fir | Wearable |
| Erfrëschungsrate | 60Hz |
| touchscreen | PCAP |
| Chauffer ic Lëscht | Built-in COF RM67162 |
| Signal Typ | MIPI (1 data lane) , Connector 30 pins |
| Spannungsversuergung | 1.8/2.8/4.6/2.4V (Typ.)(VDDIO/VCI/ELVDD/ELVSS) |
| max. Bewäertungen | Storage Temp.: -40 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
